Smiths Medical Acapella Vibratory PEP Therapy System

Smiths Medical Acapella Vibratory PEP Therapy System

Brand/Manufacturer: SMITHS MEDICAL
Save
  • HyGiene Products

Smith Medical Acapella Vibratory PEP device is designed to mobilize secretions. This PEP Therapy Device opens up the airway for effective treatment. It combines the benefits of both PEP therapy and airway vibrations to mobilize pulmonary secretions. It is ideal for people with lung disease and those with asthma and COPD. This device is very easy to use by simply placing it in the mouth, inhaling deeply, and then exhaling. Acapella lung device determines the lung capacity of the users and clears the mucus in the throat.

Acapella PEP Therapy System Includes

  • Removable mouthpiece
  • Acapella Vibratory PEP Device with 22 mm male fittings including:
  • A. Expiratory resistance/frequency adjustment dial
  • B. One-way inspiratory valve
  • C. Patient end which adapts to a mouthpiece, or mask
  • D. Mouthpiece (detachable)

Item # Desc Pkg Price
21-1530 DH with Mouthpiece, High Flow, Green Each
$74.69
$52.29
21-1015 DM with Mouthpiece, Low Flow, Blue Each
$67.19
$46.99
21-1015 + 21-1530 Acapella Blue (1) + Acapella Green (1) Therapy System Each
$128.59
$89.99
21-1015 DM with Mouthpiece, Low Flow, Blue 10/Case
$642.89
$449.99
21-1530 DH with Mouthpiece, High Flow, Green 10/Case
$714.29
$499.99

Features of Acapella Device for Breathing

  • Easier to tolerate than Chest Physical Therapy (CPT)
  • Aid in the mobilization of retained secretions, as are found in cystic fibrosis and chronic bronchitis
  • Prevent or reverse atelectasis
  • Reduce air trapping, common with asthma and COPD
  • It's easier to use than Chest Physical Therapy (CPT).
  • Helps clear mucus in conditions like cystic fibrosis and chronic bronchitis.
  • Prevents or fixes lung problems like atelectasis and air blockages in asthma and COPD.
  • Comes in different colors to match what you need.
  • You can adjust how hard you breathe through it.
  • Makes bronchodilator medicines work better.
  • Can be used in any position – sitting, standing, or lying down.
  • Faster than traditional CPT treatments.
  • There are two versions: Acapella Blue-DM for gentle breathing and Acapella Green-DH for stronger breathing.
  • It's meant for one person to use.

How does the Acapella Breathing Device work?

The Acapella Breathing Device by Smiths Medical directs exhaled air through an opening, which is periodically closed by a pivoting cone. As air passes through the opening, the cone alternately closes and opens the airflow path. The result is a vibrating pressure waveform. For most users, frequencies between 0-30 Hz are obtained while maintaining positive pressure throughout the exhalation process. This is referred to as vibratory PEP therapy.
Through adjusting the dial, the frequency of the vibrating pressure waves and the resistance of the opening changes.

Acapella Respiratory Device indications:

  • Acapella is intended for use as a single patient-use device that provides Positive Expiratory Pressure (PEP) Therapy for patients who have Cystic Fibrosis, COPD, asthma, and lung diseases with secretory problems and patients with atelectasis.
  • It may also be used simultaneously with nebulized aerosol drug delivery.
  • Green: Acapella DH is recommended for patients able to maintain an expiratory flow of 15 liters per minute or greater for 3 seconds.
  • Blue: Acapella DM is recommended for patients capable of less than 15 liters per minute for 3 seconds.

Contraindications of Acapella Medical Device

Although no absolute contraindications to the use of PEP Therapy have been reported, the following should be carefully evaluated before a decision is made to initiate therapy:

  • Inability to tolerate increased work of breathing
  • Known or suspected tympanic membrane rupture or other middle ear pathology
  • Hemodynamic instability
  • Intracranial pressure (ICP) > 20 mm Hg
  • Acute sinusitis
  • Recent facial, oral or skull surgery or trauma
  • Epistaxis
  • Esophageal surgery
  • Active hemoptysis
  • Untreated pneumothorax
  • Nausea

Benefits of PEP Therapy

  • Allows use with mask or mouthpiece attachment
  • Can be used in any position - the patient is free to sit, stand, or recline
  • Prolongs expiratory airflow to increase the removal of secretions
  • Allows use with inline nebulizer when fitted with tee adapter
  • Accommodates virtually any patient’s lung capacity
  • Allows inhalation and exhalation without removing from mouth

With vibrations added
  • Mobilizes secretions from distal to central airways
  • Loosens, shears & disengages secretions from the user's airways
  • Reduces the mucus viscoelasticity
Pressure Therapy Curve

Smiths Medical Acapella Vibratory Pep Device - Brochure

Acapella Vibratory PEP Therapy System User Guide


WARNINGS

  • Using this device at very high pressure can cause problems. Patients who are sensitive to high lung pressure might experience these issues:
  • Breathing becomes harder and may lead to not getting enough oxygen.
  • The pressure inside the head increases.
  • Problems with the heart and blood circulation.
  • Reduced blood flow back to the heart.
  • Swallowing air, which can lead to vomiting and inhaling stomach contents.
  • Feeling trapped or uncomfortable.
  • Skin irritation and discomfort from the mask.
  • Lung damage due to high pressure.


It's important for a healthcare expert to choose the right pressure setting for each patient. If the pressure setting doesn't match the patient's breathing well, it might not work properly and could lead to these issues.



What to buy with Acapella Device for Breathing

How to use Acapella Device?

Initial Settings -

  • For the first time using the Acapella DM & DH Vibratory PEP Therapy System, start by turning the frequency adjustment dial counterclockwise to the lowest resistance setting.
  • Tell the patient to relax and take a deep breath, a bit more than their regular breath but not the fullest they can.
  • Ask the patient to exhale comfortably but not too forcefully through the device until they reach a point called functional residual capacity (FRC). The device will vibrate during exhalation.
  • The patient should aim to exhale for 3-4 seconds while the device vibrates if they can't, turn the dial clockwise to make it a bit harder to exhale.
  • Adjust the dial until you achieve the right balance, which is typically a ratio of inhaling to exhaling of 1:3 to 1:4.
  • If you can't find the right balance, you might need a different device meant for different airflow.
  • Once you find the proper setting, you can fine-tune it by asking the patient to exhale harder or softer or making small adjustments to the dial.
  • It may take a few tries to get it just right for the patient's needs.

Procedure for the User -

  • Make sure the dial is set as your clinician advised.
  • Sit with your elbows on the table for comfort.
  • Gently place the mouthpiece in your mouth.
  • Keep a tight seal on the mouthpiece during exhaling.
  • You might need a nose clip if your clinician suggests it.
  • If you're using a mask, wear it snugly over your nose and mouth.
  • Breathe the way your clinician told you, taking a bigger breath than usual but not filling your lungs completely.
  • Hold your breath for 2-3 seconds.
  • Exhale actively but not too forcefully through the device, making it last about 3-4 times longer than your inhalation.
  • Do 10-20 PEP breaths as your clinician recommended. After that, remove the mouthpiece and do 2-3 huff coughs if you need to clear mucus. Your clinician can guide you on coughing properly.
  • Repeat steps 2 to 7 as directed by your clinician.

How to Clean Acapella PEP System

As needed, detach the mouthpiece, then soak the parts in warm, soapy water, rinse, and dry. Drain the device by placing the unit with the mouthpiece end downward or by resting the unit on its side.

Estimated Device Lifetime

Assuming the manufacturer-recommended cleaning protocol is followed, the Acapella Medical device should have a useful life of six (6) months under normal and customary usage. The six (6) month usage duration is measured from the date of initial use.


Acapella Vibratory PEP Therapy System FAQs

1. What is the difference between Blue and Green Acapella?

  • Green has =15 L/min expiratory flow , Blue has <15 L/min expiratory flow
  • Green is ideal for most patients, Blue is for geriatric and pediatric patients

2. How often should I use my Acapella?

Use it 2 to 4 times a day for 15 minutes (or as prescribed by your health care provider). You'll be told by your healthcare provider how many times a day you can use the Acapella device for breathing. Use Acapella 15 minutes after you inhale the drug if you are using a short-acting inhaled bronchodilator.

3. What is PEP therapy?

Positive expiratory pressure (PEP) therapy involves breathing with a slightly active expiration against expiratory resistance. It is used for the clearance of excess lung secretions, reduction of gas trapping, and improvement of lung ventilation.

4. How long does an Acapella Device can be used?

Replaced it every six months. Acapella choice is a single patient-use device and reusable.

5. What is the difference between low and high-flow units?

Low-flow unit means the unit works at less than 15 LPM (liters per minute) for 3 seconds, and a high-flow unit means that it works at more than 15 LPM for 3 seconds.

6. How to clean a pep device?

Take the mouthpiece off the Acapella body. The mouthpiece and body need to be washed. Clean the mouthpiece and body of the Acapella daily with Liquid Dish Detergent – Rinse with water.
